Water Flow Regulators



• Up to 70% Water Savings at Taps, Showers etc
• Helps comply with The Code For Sustainable Homes
•
Can help you achieve BREEAM Wat 1 credits


  • Application
  • Taps, showers & baths etc supplied by water with a minimum pressure of approx. 1 Bar (i.e. pumped/mains water supply, or gravity fed tall buildings).



  • Function
  • Point of use regulators designed to provide constant and maximum flow rates at taps and showers etc. irrespective of changes in demand or water pressure fluctuations between 1–10 Bar.



  • Benefits
  • • Large water savings and also by reducing the amount of hot used you can achieve large energy savings
    • Even water distribution throughout the site, even at peak demand periods
    • Lower capital costs (potential savings from smaller pipework, water heating systems etc.)
    • Reduced "peak demand"
    • Ideal for retro-fit or new build projects
    • Low cost solution. Payback often within months
    • Help reduce "back splash" at basins



  • Combined Isolating Valve and Flow Regulator


  •

    Order Code: RP/ACC Valve



    With access port on side of valve to allow removal of flow regulator cartridge (and optional strainer) without draining down system or breaking pipework (picture: opposite), for the purpose of flushing out the system on commisioning or changing the flow regulator cartridge to a higher or lower flow rate as required.



    Available in 15mm or 22mm sizes and comes with colour coded cap to show the flow rate the valve is set to. Flow rates and colourcoding for both sizes are:

    2.5 Lpm
    4 Lpm
    6 Lpm
    8 Lpm
    Lime Green
    Pink
    Grey
    White
      10 Lpm
    12 Lpm
    15 Lpm
    18 Lpm
    Yellow
    Brown
    Blue
    Green



    Optional strainer available upon request. Red and/or blue handles for the valves available on request.











    Order Code: 15mm RP/ISO



    15mm combined flow regulating & isolating valve with integral flow regulator. Optional handle available on request. Optional strainer available on request.



    Flow rates from any of 4, 6, 8, 10, 12 or 15 Lpm.









    Flow Regulator Insert
    Order Code: RP/GA



    Circular flow regulator insert (only) for your own valves. Simply fit in to the tap/appliance side of your own compression ended valve.



    Flow rates for 15mm 4, 6, 8, 10, 12, 15 and 18 Lpm.



    Flow rates for 22mm 8, 10, 12, 15 and 18 Lpm.





    Combined Aerator & Flow Regulator
    Order Code: RP/CAAFR

    Aerators add air into the water as it leaves the tap in order to help reduce splashing when water hits the basin.



    No plumbing required to fit. Simply replace existing tap aerator with this unit.

    Flow rates/colour-coding as follows:

    1.9 Lpm
    3.8 Lpm
    5 Lpm
    Lime Green
    Blue
    Orange
      6 Lpm
    8 Lpm

    Black
    White









    Combined CARE Insert (flow straightener) and Flow Regulator
    Order Code: RP/CARE



    Mainly used for medical applications as the laminar flow does not aspirate air into the water. No plumbing required to fit. Simply replace existing tap aerator with this fitting. Flow rates as combined Aerator and Flow Regulator (above).







    Combined Spray and Flow Regulator
    Order Code: RP/SPRAY



    Mainly used for applications where very low water consumption is required. Pressure compensating from 0.8 Bar– 5 Bar. No plumbing required to ?t. Simply replace existing tap aerator with this fitting.



    Flow rates/colour-coding as follows:

    1.7 Lpm
    2 Lpm
    2.5 Lpm
    3 Lpm
    Light Grey
    Dark Grey
    Green
    Lilac
      3.5 Lpm
    4 Lpm
    5 Lpm
    Dark Blue
    Pink
    Orange







    ½" Shower Flow Regulator
    Order Code: RP/SFR/DW



    Ideally ?t this unit at the thermostatic mixing valve end of the ?exi-hose. If ?xed head shower, unscrew the showerhead, screw the ?ow regulator in and then re-?t the shower head. No plumbing required to it.



    Flow rates/colour-coding as follows:

    4 Lpm
    6 Lpm
    8 Lpm
    9 Lpm
    Grey
    Black
    White
    Orange
      10 Lpm
    12 Lpm
    15 Lpm
    Blue
    Red
    Lime Green







    ½" MxF Chrome Tap Tail/Mixer & Flow Regulator
    Order Code: RP/DWSA/TTFR



    Simply screw on to ½" inlet pipe thread to an appliance.



    Flow rates/colour-coding as follows:

    1.4 Lpm
    1.9 Lpm
    2.5 Lpm
    3.5 Lpm
    5 Lpm
    Brown
    Yellow
    Orange
    Red-brown
    Violet
      6 Lpm
    8 Lpm
    9 Lpm
    10 Lpm
    12 Lpm
    Pink
    Red
    Lilac
    Black
    White



    Our Products

    The products we supply are on the Qualified Water Technology List and / or WRAS approved where you see these symbols.
