Security Sanitaryware

Conventional safe-ensuite sanitaryware, apart from being extremely heavy and difficult to handle/manoeuvre, can be broken and shatter producing dangerous shards of material for self harm or harm to others.

Anti-vandal, anti-ligature and fire resistance tested by The Home Office

High impact resistance and will not shatter. Made using techniques employed in the fields of ballistic armour.
High grade polyester gel coated surface which produces high chemical & ultraviolet resistance.
Lighter than most conventional safe-ensuite sanitaryware; the WC pan weighs under 20 kg.
Ideal for Prisons, Police Cells, Mental Health Units and other custodial/municipal applications where vandalism is a high risk.

High Security WC Pans

Concealed rear waste outlet
Large trap to reduce blockages
Optional side in-fills
Optional (taller) disabled WC Pan

Standard fixing kit is for 100mm wall thickness. If wall is thicker than 100mm please confirm total wall thickness as you will need optional extension threads.

Floor Standing WC Pan

Wall Hung WC Pan

Optional brackets which fit on other side of panel to strengthen it if required.

HSTC - Concealed Cistern (Tall)

HSSSB-DIS - Spacer Box (For use only with disabled WC Pan)

Order Codes:	Product Description
HSFP	Floor Standing WC Pan
HSFP-BLUE-GEL	Floor Standing Blue Gel WC Pan
HSFP-DIS	Disabled WC Pan (60mm higher than standard pan)
HSSSB-DIS	Disabled White Steel Spacer Box
HSWP	Wall Hung WC Pan
HSWP-BLUE-GEL	Wall Hung Blue Gel WC Pan
HSTC	Tall WC Cistern Kit (2" Base)

Fully Integrated all in one Basin and Backplate

Order Code: HSWHB-INT

Order Code: HSWHB-INT-MONO

Rear concealed waste outlet.
Ligature resistant.
Wave on or tactile control options available.
In built water spouts and moulded soap shelves c/w stainless steel anti-ligature waste grid.
Optional lock out facility
Basin c/w 70mm Fixing Kit.
Backplates include spouts.
Optional extension threads available for thicker walls.
Backplates do not include sensors or touchpads. These need to be ordered separately.

High Security Basin & Standard Backplate

Standard Backplate for High Security Basin

Optional Backplate with Shelf

Order Codes:	Product Description
HSWHB	High Security Basin (only)
HSWHB-BP-COMPLETE	Basin & Standard Backplate
HSWHB-BP	Standard Backplate for Basin
HSWHB-BP-Shelf	Optional Backplate With Shelf

High Security Basin & Backplates Accessories

HSM Shatterproof Mirror

Order Codes:	Product Description
HSM	Shatterproof High Security Mirror
HSWG	Waste Grid
HSRP	Replacement Rubber Bag

High Security Backplates for use with your own bath/basin

With longer spout projection

Remote Backplate for Basin

Order Code: HSBP-BASIN (c/w 5Lpm flow regulator)

Remote Backplate for Bath

Remote Backplate for Bath: HSBP-BATH (c/w no flow regulator to ensure high flow)

Steel Bath Backplate

To control water to a seperate bath spout.

Dimensions: 160mm x 110mm

Order Code: SSHFBP

Ensuite Washroom Control Systems

Features:

Single control box can control a basin with 2 spouts, a WC and a shower
Anti-ligature no-touch sensor (or optional electronic touchpad switch) operation
Optional lock-out facility
Optional purge facility

Washroom Control Box

Order Code: HSWBC

Washroom Control Box (with controls for WC, Basin & Shower)

Remote Key Switch

Order Code: HSKEYSW

Water control key switch c/w 5m cable (suitable for use with washroom control system for isolating water or re-setting lockouts)

Ensuite Control Packages

Ensuite Control Package 1 - High Risk (excluding shower)

Package 1 includes:

Washroom Control Box
15mm TMV3 Thermostatic Mixing Valve c/w strainers and check valves
2 No. 15mm Solenoid Valves
High Security Standard Backplate (and 2 No. Sensors; 1 for hot water, 1 for cold water)
High Security Basin
WC anti-Vandal wave-on Sensor
WC Flushvalve
Concealed Cistern Kit
High Security WC Pan

Does not include sensor and valve for shower

Order Code: Ensuite Control Package 1 - High Risk

Ensuite Control Package 2 - High Risk (including shower)

Package 2 includes everything in Package 1, but also includes:

Shower Sensor for Showerhead
Vandal Resistant Showerhead
Additional 15mm TMV3 Mixing Valve c/w Strainers and Check Valves
Additional 15mm Solenoid Valve

Order Code: Ensuite Control Package 2 - High Risk

Battery Powered Kits

Basin Backplate Controls - Battery powered

TPTS-B/HP/Basin Backplate Sensor kit
TPTS-B/HP/Basin Backplate Touchpad kit

Bath Backplate Controls - Battery powered

TPTS-B/HP/Bath Backplate Sensor kit
TPTS-B/HP/Bath Backplate Touchpad kit

Each kit c/w:

1 x control box & battery pack
2 x 15mm HP 6v solenoid valves
2 x pre-wired sensors or touchpads (1red, 1 blue).

Standard High Pressure (HP)

6v solenoid valves rated for water pressure 0.75 bar – 10 bar.

Optional Low Pressure (LP) version

With solenoid valves rated for 0 bar – 1.5 bar.

Optional Very Low Pressure (VLP) version

With solenoid valves rated for 0 bar – 0.5 bar

Optional extras for Ensuite Control Packages 1 & 2:

Panel or Wall? Standard product is designed to fit through a normal thin panel. If fitting through a thick brick wall you will require optional extension threads. If in doubt please confirm total wall thickness so we can price for any relevant extension threads required.
Water Pressure/Solenoid Valves. The standard solenoid valves supplied are 15mm size and rated for water pressure 0.5 bar – 6 bar. We do offer optional low pressure solenoid valves, so if required please confirm actual water pressure on site so we can advise/quote for the relevant low pressure solenoid valves.
"No-touch Sensor" or optional electronic "Touchpad Switch" operation. Standard kit supplied is anti-ligature no touch sensor. If you prefer anti-ligature touchpad switches please advise.

If you do not want a complete Ensuite Package – eg you only want to use a high security backplate with your own basin – we can offer individual "No-Touch" sensor (or electronic touchpad) controls suitable for our high security backplates.

Mains Powered Kits

Basin Backplate Controls - Mains powered

TPTS-M/HP/Basin Backplate Sensor kit
TPTS-M/HP/Basin Backplate Touchpad kit

Bath Backplate Controls - Mains powered

TPTS-M/HP/Bath Backplate Sensor kit
TPTS-M/HP/Bath Backplate Touchpad kit
